FPV Drone LiPo Battery — Industrial B2B Product Guide



High-performance FPV LiPo battery packs engineered for sustained high-current draw, minimal voltage sag, and strict cell-to-cell voltage variance. Built for commercial drone builders, FPV brands, and industrial distributors requiring reliable OEM/ODM lithium power solutions.
Target Applications: 5-inch freestyle quads, long-range exploration rigs, heavy-lift cinematic cinewhoops, and industrial inspection drones.
Target Audience: Drone manufacturers, B2B wholesale distributors, and commercial UAV system integrators.




First 1234 Last

Key Features & Performance Advantages

Ultra-Low Internal Resistance (IR):

Automated tab-welding and high-grade copper nickel strips keep IR under 1.2 mΩ per cell, verified via automated impedance testing before pack assembly to minimize thermal buildup during high-amp transient loads.

Stable Discharge Curve Under Load:

Formulated with high-conductivity lithium cobalt oxide chemistry to maintain voltage plateau stability under 100C to 150C discharge rates, preventing sudden power throttling during aggressive flight maneuvers.

Optimized Energy Density Ratio:

Precision electrolyte balancing delivers a high mAh-to-weight ratio (mAh/g), extending flight times without imposing excessive payload weight on the frame.

Factory-Matched Cell Consistency:

Pre-assembly sorting groups cells by internal resistance and capacity within a ±1 mV tolerance window, preventing premature pack imbalance and extending operational cycle life.



Technical Specifications





Parameter

Specification Range

Chemistry

Lithium Polymer (LiPo) / High-Voltage LiPo (LiHV)

Cell Configuration

3S to 6S (Custom series/parallel builds available up to 12S)

Nominal Voltage

11.1 V (3S) to 22.2 V (6S) / 11.4 V to 22.8 V (LiHV)

Capacity Range

1300 mAh to 6000 mAh

Continuous Discharge Rate

100C – 150C

Burst Discharge Rate

Up to 200C (3-second pulse)

Standard Charge Rate

1C to 5C (Rapid charging supported)

Discharge Connectors

XT60, XT90, EC5, QS8

Balance Connectors

JST-XH standard

Wire Gauge

10AWG / 12AWG / 14AWG high-strand silicone wire (heat-resistant up to 200°C)

Typical Applications & Use Cases
Freestyle & Racing FPV:
High burst discharge and rapid transient recovery for agile, high-G acrobatic flight and competitive racing quads.
Cinematic FPV:
Stable voltage output and reliable endurance for heavy cinema camera payloads (RED, Blackmagic, mirrorless systems) mounted on 7-inch to 10-inch long-range platforms.
Industrial & Commercial UAVs:
Extended hover endurance and thermal stability for aerial mapping, search and rescue, utility inspection, and automated patrol drones.



Customization & OEM/ODM Capabilities


Tailored manufacturing configurations to align with exact platform integration requirements:

Electrical Architecture:

Custom cell capacity, discharge rates, voltage configurations (3S to 12S), and integrated smart BMS (Battery Management System) options.

Physical Dimensions:

Custom width, length, and height profiles, as well as specialized soft-pack or hard-case rigid enclosures.

Interface & Cabling:

Custom wire length, tailored wire gauges (10AWG–16AWG), and specialized connector soldering (XT60, XT90, AS150, or custom proprietary plugs).

Branding & Labeling:

Custom PVC shrink-wrap color schemes, laser-engraved connectors, and private-label packaging with custom barcode or QR serialization.

Quality Control, Testing & Compliance

Rigorous in-house testing protocols ensure batch consistency and operational field safety:

Cell Sorting & Grading:

Automated testing equipment measures internal resistance, open-circuit voltage, and discharge capacity under load before pack pairing.

Assembly Verification:

100% factory inspection covering ultrasonic tab-weld pull testing, dimension verification, and final pack voltage balancing.

6S-22.2V 4000mAh 130C FPV Racing Lipo Battery
3S-11.1V 750mAh 100C FPV Racing Lipo Battery

Destructive & Stress Testing:

Regular batch testing for overcharge, over-discharge, short-circuit protection, thermal shock (85°C oven exposure), and drop/vibration simulation.

Regulatory Compliance:

Full documentation and certification support for UN38.3, MSDS, CE, RoHS, and FCC standards to ensure seamless global customs clearance.

Packaging & Supply Chain Logistics




Packaging Standards:

Anti-static individual packaging, reinforced inner partition boxes, and UN-certified dangerous goods (DG) outer cartons.




Minimum Order Quantity (MOQ):

100 units per specification for standard stock models; 500 units for custom OEM/ODM configurations.




Lead Time:

7 to 10 business days for standard inventory sample dispatch; 20 to 30 days for bulk OEM production runs.




Shipping Channels:

Dedicated dangerous goods (DG) logistics support for air cargo and sea freight compliant with international lithium battery transport regulations.







Frequently Asked Questions





Q: What is the exact cell voltage tolerance before final pack assembly?

A: All individual cells are matched within a ±1 mV delta to ensure uniform discharge rates and prevent localized cell degradation over repetitive charge cycles.

Q: Can you supply custom connector types soldered directly to the harness?

A: Yes. We maintain standard RC inventory (XT60, XT90, EC5, QS8) and source specialized industrial power plugs according to engineering blueprints.

Q: What is the minimum order quantity (MOQ) for custom private-label shrink wrap?

A: The MOQ for custom branding, logo printing, and specialized PVC color wrapping starts at 500 units per model type.

Q: Are official test reports included for air and ocean freight customs clearance?

A: Yes. Every bulk export order includes UN38.3 test summaries, MSDS safety sheets, and factory QC inspection logs.

Q: What is the standard production lead time for bulk volume orders?

A: Standard production runs take 20 to 30 days following engineering specification sign-off and deposit confirmation.

Q: Do you offer High-Voltage LiPo (LiHV) cell options for extended flight times?

A: Yes. LiHV cells capable of safely charging to 4.35 V per cell are available across our standard and custom capacity manufacturing lines.



modular-1
Request a Quote, Samples & Technical Support

Contact our engineering and sales team for volume pricing tiers, technical drawing reviews, or customized OEM sample prototyping.
