Custom High-Discharge LiPo Battery Packs for RC Helicopters & UAV OEMs


High-discharge Lithium Polymer (LiPo) battery packs engineered to sustain stable voltage under extreme load profiles demanded by RC helicopters, fixed-wing aircraft, and high-performance UAV platforms. Built using automated stacking and ultrasonic tab welding processes to eliminate voltage sag during aggressive 3D maneuvers and vertical climbs.

Primary Application:

3D aerobatic helicopters, turbine/EDF jets, heavy-lift fixed-wing FPV platforms, and commercial agricultural drones.

Target B2B Buyers:

RC hobby brands, regional electronics distributors, drone manufacturers, and specialized model assembly houses.

Core Supply Offering:

OEM pack configurations (voltage, capacity, discharge rate, wire gauge, and connector termination) backed by in-house batch testing and UN38.3 compliance.




First 1234567 Last

Key Features & Performance




Ultra-Low Internal Resistance (IR):

Automated sorting and ultrasonic tab welding maintain single-cell IR variance within ±0.5 mΩ, minimizing thermal buildup under heavy current draws.




High Continuous Discharge (C-Rate):

Formulated with high-conductivity cathode chemistry supporting sustained 50C to 120C outputs without premature capacity fading.




Rigid Stacking Architecture:

Multi-layer ceramic separators and aluminum-laminated pouch containment prevent mechanical deformation during high g-force transitions.




Optimized Energy-to-Weight Ratio:

Delivers up to 220 Wh/kg, maximizing flight duration without exceeding airframe payload limits.





Specifications





Parameter

Standard Specifications (Customizable)

Nominal Voltage

11.1V to 44.4V (3S to 12S configurations)

Capacity Range

1300mAh to 10000mAh

Discharge Rate

50C Continuous / 100C Burst (up to 120C specialized grades)

Cell Chemistry

High-Rate Lithium Polymer (LiPo)

Standard Dimensions

Tailored to compartment cavities (Length: 70mm–200mm, Width: 34mm–60mm)

Weight Tolerance

±5 g per finished pack

Discharge Leads

10AWG to 14AWG high-strand silicone wire

Connectors

XT60, XT90, EC5, AS150, IC5, or bare leads

Balancing Plug

JST-XH standard (custom locking connectors available)



Applications


3D Competition Helicopters:

Delivers immediate torque response for collective pitch pumps and rapid cyclic inputs without sudden low-voltage cutoffs.

Fixed-Wing Aerobatic & Pattern Planes:

Maintains level-flight voltage curves during vertical rolls and large-radius aerobatic maneuvers.

Ducted Fan (EDF) & Turbine Jets:

Handles sustained high-amp loads required by high-RPM electric ducted fan propulsion units.

Long-Range & Mapping UAVs:

Powers extended autonomous flight legs with predictable linear discharge curves down to 3.5V/cell.



Customization (OEM / ODM)

Production lines accommodate customized OEM/ODM requirements for branded distribution:

Cell Configuration:

Custom series (S) and parallel (P) arrangements matching exact voltage and run-time targets.

Enclosure & Protection:

Hard-case polymer shells, soft silicone jacket wraps, or integrated fiberglass reinforced plates.

Wiring & Interface:

Specified wire gauge lengths, dual-discharge leads, and pre-soldered connector types matching ESC requirements.

Labeling & Packaging:

Laser-etched shrink wrap, private label brand logos, anti-static bulk cartons, and hazard warning inserts.



3S-11.1V 3800mAh 25C LiFePO4 Battery



Quality Control & Safety Compliance

Manufacturing adheres to strict quality gates utilizing automated sorting and testing equipment:


Cell Matching: Automated grading machines sort cells by capacity, open-circuit voltage (OCV), and AC impedance before spot welding.


Testing Protocols:

  • Vibration testing simulates multi-axis transport and high-frequency airframe resonance.
  • Thermal chamber cycling from -20°C to +60°C.
  • Simulated short-circuit and overcharge burst testing on sample production lots.


Certifications: UN38.3 transport compliance, CE, RoHS, and MSDS documentation provided for air and ocean freight forwarding.



Packaging & Supply Chain



Protective Packaging:

Individual anti-static bubble sleeves, compartmentalized inner fiber boxes, and UN-certified outer corrugated shipping cartons.

01

Minimum Order Quantity (MOQ):

100 pieces per voltage/capacity SKU for standard stock; 500 pieces for custom OEM branding.

02

Lead Time:

15 to 25 business days for custom production runs; 3 to 7 business days for standard off-the-shelf catalog configurations.

03

Logistics Support:

Direct partnership with dangerous goods (DG) freight forwarders experienced in lithium battery export compliance.

04





Frequently Asked Questions





Q: What is the typical cycle life before capacity drops below 80%?

A: Under standard operating conditions (discharge rates below 80% of max C-rating, cut-off voltage maintained above 3.6V/cell, and ambient charging temperatures between 15°C and 35°C), packs deliver 150 to 200 charge-discharge cycles.

Q: How do you control cell swelling (puffing) during high-load usage?

A: Internal resistance is minimized during tab welding, and high-purity cathode/anode slurry formulations are used to prevent excessive gas generation under high-temperature operation. Proper cooling airflow design in the airframe is still recommended.

Q: Can we request specific wire lengths and non-standard connectors?

A: Yes. Production lines can install custom wire gauges (10AWG to 14AWG), variable wire lengths, and specific industrial connectors (such as AS150 or XT90-S with anti-spark resistors) according to CAD drawings or sample specifications.

Q: What documents are provided for customs clearance and air shipping?

A: Every shipment includes the UN38.3 Test Summary Report, Material Safety Data Sheet (MSDS), Commercial Invoice, Packing List, and factory batch test reports.

Q: Do you supply matching balance chargers or testing equipment?

A: While the core focus is manufacturing battery packs, compatible high-wattage multi-channel smart chargers and cell checker accessories can be bundled upon request for wholesale distribution.

Q: What is your policy regarding sample evaluation for OEMs?

A: Sample batches of 2 to 5 units are available for laboratory testing, internal resistance logging, and flight validation prior to issuing volume purchase orders.



modular-1
Request a Quote, Samples & Technical Support

To initiate an inquiry for wholesale pricing, custom OEM configurations, or laboratory evaluation samples, submit specifications to the engineering team:
Required Information: Target capacity (mAh), voltage (S-count), discharge C-rate, estimated annual volume, and destination port.
Response Window: Technical proposals and quotation sheets are returned within 24 business hours.
